DESCRIPTION

Air purification system for sensitive products or processes.

Automated control via PLC of the air purification process to ensure the product/process safety and healthiness.

BENEFITS

  • NO airborne contamination of the product/process.
  • Simple and cost-effective: low running costs, low and easy maintenance.
  • Stand-alone unit ready to install, easy integration into existing installations, NO production downtime.
  • Wide range of applications

PERFORMANCE

  • Prefiltration: more than 50% of the 0.3 ÷ 10 µm particles are retained by the filter.
  • Disinfection: maximum germicidal action thanks to 254 nm wavelength UV irradiation.
  • 5-log pathogen reduction thanks to the final HEPA H14 filter (99.995%).
  • 3 treated air separate outlets, to connect several items at the same time.

MAIN FEATURES

  • Double protection from unwanted contamination: UV sanitizing lamp + HEPA H14 antibacterial filter.
  • Hygienic and ECO-friendly design.
  • Waterproof stainless steel (aisi304) construction (IP54 certification).

CONTROL PANEL

  • PLC for local and remote machine and alarm management
  • Backlit control panel displaying all the working information
  • Ethernet communication
  • Filter clogging sensor alarm
  • UV sensor alarm
  • Maintenance alarm
  • Multi-voltage and multi-frequency : 110 ÷ 220 V; 50 ÷ 60 Hz.

PREFILTER

  • Filtration degree: ISO coarse 55%
  • Filtering surface: 0,34 m2
  • Filter material: progressive density synthetic fibre
  • Entirely recyclable (different materials must be separated).

UV UNIT

  • Dosage: 20 mJ/cm2
  • Guaranteed for at least 9000 hours of continuous operation
  • Type: single-ended for easy replacement
  • Reflective aluminium surface to enhance the UV ray effectiveness
  • Air deflector to improve air distribution inside the UV chamber.

HEPA FILTER

  • Filtration degree: HEPA H14 (99.995%)
  • Filtering surface: 10,6 m2
  • Operation conditions limits : relative humidity 100%, temperature 80°C
  • Filter material: Water repellent glass fibre paper
  • Frame: wood (recyclable).
